PRODUCT SPECIFICATIONS

• Secondary Protection
• LED Indicators / Sneak Current Protection Yes
• Grounding Requirements Field installed solid copper wire
  for Secondary 1-6 pairs 14 AWG
  for Secondary 7-25 pairs 6 AWG
• Recommended Grounding Impedance <0.5 Ohm
• PTC Rating 160mA (8-10 Ohms)
• Applications Data / Voice / Fax / Modem lines
• Width / Height / Depth / Weight 1.88” / 2.62” / 0.38” / 0.04 lbs
• Product Warranty 5 years

SIGNAL LINE SURGE PROTECTION: (TELCO)

• Signal Perfect Circuitry Yes
• Auto-Resettable Yes
• Clamping Level 39V, 75V, 235V
• Response Time 1-5 Nanoseconds
• Capacitance <50pF
• Suppression Modes Metallic & Longitudinal
• Wires Protected 2-wires, 1-pair
• Termination Type 66 type M Blocks

FEATURES

• Dual Indicator Lights Protection OK and Ground Connection OK
• Solid-state Protection Provides the fastest response
• Single Pair Protection Scale the protection to the system size. Protect only the lines requiring protection
• Streamlined Installation Eliminate redundant cross-connects by adding protection directly at the 66 Block. Press fit protectors to the block and attach the ground bar to the protectors. A Screw Ground Lug also is required. (MGBSGL-1)
• Sneak Current Protection Protects against fires caused by overloads and power crosses
• Cost Savings Eliminate expensive five-pin blocks and use economical 66 Blocks
• Optimum Protection Available in a number of voltage ratings to match system operating voltages
• Ideal for Retrofit Applications Just remove the bridging clips from the block & replace them with the UltraLinx Protector, add the ground connection and the pair is protected
• 5 Year Product Warranty This surge protector shall be free of any defects in design, materials, or workmanship, or ITW Linx will repair or replace the defective product
